Aftermarket Replacement PV Series Piston Pumps

PV Series Piston Pumps

The PV series is a swashplate-type axial piston variable pump for open circuit, rated 350 bar nominal with 420 bar peak. The family spans 6 frames and 14 displacements (016–360 cm³/r). Common controls include MM (pressure compensated), MR (remote pressure), MF (load sensing), MT (two-spool load sensing), XL / XC / XZ (power control) and FDV / UD* (electro-proportional). All units are new aftermarket replacements, quality checked before shipping; selection follows the full 15-position nameplate code.

Technical data — PV series

Frame123456
Displacement Vg max (cm³/r)016–028032–046063–092140–180270360
Flow at 1500 rpm (l/min)24–4248–6994.5–138210–270405540
Input power at 350 bar (kW)15.9–26.931.1–43.861.3–87.5136.1–173.1259.6338.7
Max torque (N·m)94.5–165184–265365–533812–104415502067
Max speed (rpm)300028002300–28002200–240018001750
Weight (kg)19305990172180
Nominal / peak pressure350 bar nominal / 420 bar peak
Circuit & designOpen circuit, swashplate design
Fluid & cleanlinessHLP, viscosity 16–100 mm²/s, ISO 4406 20/18/15

Available controls

  • MM — standard pressure compensation
  • MR — remote pressure control
  • MF — load sensing (flow) control
  • MT — two-spool load sensing control
  • XL / XC / XZ — power control / power + load sensing
  • FDV / UD* — electro-proportional (p/Q) control

Typical applications

The PV series is used in industrial and mobile circuits that need 350-bar class pressure with accurate pressure or flow control — injection moulding machines, presses, machine tools, test rigs and mobile main pumps. Always match by the full nameplate code: prefix, displacement, rotation, coupling, flange/shaft, ports, thru-drive, variation, seal and the 3-digit control position (15 positions in total).

Need help choosing the right pump? Send us the full model code from your existing nameplate — we will confirm the correct configuration before you order. Contact us

New aftermarket PV series axial piston variable pumps — 6 frames and 14 displacements from 016 to 360 cm³/r, 350 bar nominal / 420 bar peak. Common controls MM, MR, MF, MT, XL, XC, XZ and the electro-proportional FDV / UD versions. Supplied against the full 15-position nameplate code; quality checked before shipping.

PV Series Piston Pumps

New aftermarket PV series axial piston variable pumps — 6 frames and 14 displacements from 016 to 360 cm³/r, 350 bar nominal / 420 bar peak. Common controls MM, MR, MF, MT, XL, XC, XZ and the electro-proportional FDV / UD versions. Supplied against the full 15-position nameplate code; quality checked before shipping.

Showing 1–24 of 2056 results
